Specifications

 Q 3050i – Floorstanding Front Speakers (×2)

• Enclosure Type: 2-way reflex

• Bass Drivers: 2 × 165 mm (6.5 in)

• Tweeter: 22 mm (0.9 in)

• Frequency Response (+3 dB, –6 dB): 44 Hz – 30 kHz

• Impedance: 6 Ω nominal (4 Ω min)

• Sensitivity: 91 dB (2.83 V @ 1 m)

• Recommended Amp Power: 25 – 180 W

• Dimensions (H×W×D): 1020 × 310 × 310 mm

• Weight (each): ~17.8 kg

Q 3010i – Bookshelf / Surround Speakers (×2)

• Enclosure Type: 2-way reflex

• Bass Driver: 100 mm (4 in)

• Tweeter: 22 mm (0.9 in)

• Frequency Response (+3 dB, –6 dB): 65 Hz – 30 kHz

• Impedance: 6 Ω nominal (4 Ω min)

• Sensitivity: 86 dB (2.83 V @ 1 m)

• Recommended Amp Power: 15 – 75 W

• Dimensions (H×W×D): 253 × 150 × 252 mm

• Weight (each): ~4.1 kg

Q 3090Ci – Centre Speaker

• Enclosure Type: 2-way reflex

• Bass Drivers: 2 × 100 mm (4 in)

• Tweeter: 22 mm (0.9 in)

• Frequency Response (+3 dB, –6 dB): 75 Hz – 30 kHz

• Impedance: 6 Ω nominal (4 Ω min)

• Sensitivity: 89 dB (2.83 V @ 1 m)

• Recommended Amp Power: 25 – 100 W

• Dimensions (H×W×D): 152 × 430 × 216 mm

• Weight: ~6 kg

Q 3060S – Active Subwoofer

• Enclosure Type: Infinite baffle

• Driver: 200 mm (8 in)

• Amplifier Power: 150 W Class D

• Frequency Response (+3 dB, –6 dB): 35 – 250 Hz

• Crossover Range: Adjustable (varies)

• Dimensions (H×W×D): 480 × 300 × 150 mm

• Weight: ~8.5 kg
